Spare Part Number:
DJ-020
Net Weight:
544.30g
Net Dimensions:
119.00mm x 119.00mm x 38.00mm
Technical Datasheet:
Protected Link
Certification: Protected Link - CE Declaration
Manual: Protected Link
Certification: Protected Link - CE Declaration
Manual: Protected Link
DJ-020 Fan/Blower
AC Axial Fan implemented as integral part of a cooling solution for heat-generating equipment areas. The fan features a shaded pole induction motor and an expected life of about 100,000 hours.
Papst 120mm 230V
| Product Attribute | Attribute Value |
|---|---|
| AC Fans | |
| Axial | |
| 119 mm | |
| 38 mm | |
| 119 mm | |
| 230 VAC | |
| 49.4 CFM (1.4 m3/min) | |
| Ball | |
| 28 DBA | |
| 1450 RPM | |
| 6 W | |
| Aluminum | |
| Quick Connect Terminal | |
| Current Type: | AC |
| Pressure Type: | 0.59 in H2O |
| Product Type: | AC Fans |
| Unit Weight: | 544,300 g |
810 Ref V4. V5. V6. V7
812 Ref V4. V5. V6. V7
| Suitable for the following equipment models: | |
|---|---|
| EVO 3 EDLF | |
| EVO 3 ELF | |
| EVO 4 E | |
| EVO 4 EDLF | |
| EVO 4 ELF | |
| EVO 5 E | |
| EVO 5 ELF | |
| Spare Part Type | |
| Electrical Component | |
| Spare Part Group | |
| Blower | |
| Stock Type | |
| Standard Stock | |
